Chicken Laying Nesting Box for Breeder Farm: Automatic Roll-Out Nest System for Large-Scale Poultry Houses

For breeder farm operations that need steady egg production with little labour, Shandong Huabang Agricultural And Animal Husbandry Machinery Co., Ltd. developed and produces the chicken laying nesting box for breeder farm. Each unit is 1.2m long, 1.4m broad (1.88m with perch) and 2m high including the perch and is made from zinc-aluminium-magnesium plate. The nest box houses roughly 120 birds each set, keeping egg breakage around 0.3%, and works on a 0.4 kW front motor and a 0.75 kW rear motor. Each set weight is 40kg. We provide 1 year guarantee. huabang’s engineering team support for technical help.

Chicken Laying Nesting Box for Breeder Farm Overview

This product setups integrates egg-collecting platform, laying nest, storage box, and conveying tail portion into one automated nest structure for breeder hens and commercial layers.

You just hook it up to automated egg collecting lines. So your chicken house layout is neat and staff don't have to waste their time wandering the aisles selecting eggs by hand.

Material and Structural Design

Poultry buildings are rich in ammonia and are always damp. The body of the nest is built from zinc-aluminum-magnesium sheet that can withstand this kind of corrosive air significantly longer than simple steel sheets.

The supporting frame is 3mm thick hot-dip galvanised steel which increases the service life of the frame compared to thinner steel sheets.

In the center of the unit is a 5cm raised structure. This little raise allows airflow to circulate beneath the nest, which helps keep temperatures down in hotter months and helps minimise moisture build up around the eggs.

Technical Specifications

Core Advantages

Lower Egg Breakage Rate

Eggs are softly rolled onto the belt in a buffer type egg rolling arrangement as opposed to dropped or violently slid. If this buffer phase is skipped, eggs are more prone to cracking or pecking damage when they roll straight onto a belt. With this buffer design, the breakage is kept below 0.3% with standard feeding control.

Anti-Broody Nite Lift

After dark, a built-in raising mechanism lifts the nest body. This discourages hens from roosting within the nest overnight, which helps to reduce dirty eggs and faecal build-up, decreasing the need for personnel to wash out nests by hand each morning.

Self-Adjusting Belting

The back of the egg belt automatically adjusts tension and compensates for sideways movement. This maintains the belt centred over extended production shifts, reducing the need for human recalibration and downtime. The open belt design also allows feathers and dried debris to drift away rather than stack up against the shell, which helps keep bacteria levels on the eggshell lower. Without this self-adjusting capability, a belt is more likely to slide or jam, which may require additional downtime for human repairs.

Integrated Modular Construction

The egg-collecting platform, laying nest, storage box and conveyance tail part are all housed in a single unit. It can be connected with most of the automated egg collecting lines without additional adapters, suitable for large-scale standardised chicken coops, one-stop project matching from design to installation.

Lower cost of labour

Automatic egg collecting takes the workers out of the laborious picking. This helps to save labour hours, maintain consistent egg output quality and control expenses during each production cycle for breeder and commercial layer operations.

Motor and Drive System

The conveying system is driven by two motors. The front motor is 0.4 kW and the rear is 0.75 kW providing the belt with sufficient pull for lengthy egg lines without any added strain on either end.

The split motors share the labour along the line so that the eggs travel at a consistent speed from nest to collecting point. If you buy more nest units for a longer chicken house the team may adjust the motor output to the increased length.

Applications

This nest box is sized for commercial laying hen homes, and works equally as well for breeding chickens on big scale poultry farms. The tiny nest body also works well for backyard installations, although the primary design aim is still huge breeding and layer operations.

This chicken laying nesting box for breeder farm unit may be added to existing automated egg lines without a complete system rebuild on farms using multi-tier cage systems, floor-rearing homes, or mixed breeding setups.

Customization and Support

Huabang customises this chicken laying nesting box for breeder farm setup depending on the length of your chicken house. Tell the staff how big your home is and they'll add or remove nest units to fit the space you have.

Technical personnel provide setup advice for installation and commissioning, ensuring your team gets belt tension, the lifting mechanism, and motor wiring correct from the start.

Standard production runs are 30-60 days, supported by 17 years of design and manufacturing experience with intelligent livestock equipment. Huabang also operates ISO9001 and CE certified production system, direct factory shipment, and OEM/ODM orders created from customer designs and specifications.

FAQ

Q: For which chicken breeds is this automated chicken nest box suitable?

A: It is used mostly for commercial laying hens, but is also suitable for breeder hens on large scale chicken breeding farms.

Q: Can you make the amount or size according to our chicken house?

A: Yes, The crew may add nest units and alter the arrangement to fit the length of your chicken coop.

Q: Is there technical help for the installation and commissioning?

A: Yes. We will have technicians from Huabang to guide and help us in installation.

Q: How many eggs do you break with this roll-out nesting box?

A: Under typical feeding management and standard installation, the breaking rate is less than 0.3 %.

Q: Will this product work for backyard or small farms?

A: It will work for commercial farms and tiny home breeding operations, yes.

Q: What warranty and aftersales service do you get with this nest box?

A: All units come with a 1 year guarantee and Huabang’s staff is accessible for after-sales queries and parts assistance.
