H Frame Automatic Layer Cages

H Frame Automatic Layer Cages - Fully Automated Poultry Housing System

Shandong Huabang Agricultural And Animal Husbandry Machinery Co., Ltd. delivers industry-leading H Frame Automatic Layer Cages engineered for large-scale commercial egg production. Our system features a robust 275g/m² hot-dip galvanized steel structure with dimensions of 1200mm × 1200mm × 450mm per unit, accommodating 90-200 chickens per set across customizable 3 to 8-tier configurations. With an exceptional egg breakage rate below 0.3%, our solution integrates automated feeding, egg collection, and manure removal systems, reducing labor costs by up to 80%. Backed by 17 years of manufacturing expertise and ISO9001/CE certifications, we serve poultry farms across 100+ countries with turnkey installation support and 1-year international warranty coverage.

What Makes Our H Frame Automatic Layer Cages Superior

This vertically stacked poultry housing system utilizes an 'H' shaped structural profile specifically designed to maximize land utilization in commercial operations. The centralized manure belt configuration separates waste from living areas, dramatically improving biosecurity compared to traditional A-frame designs.

Your farm will benefit from full-process automation. Automated egg collection corridors use shock-absorbing mesh to gently transfer eggs, while precision feed distribution technology provide uniform nutrient supply throughout all levels.

The modular architecture may accommodate operations with 500 birds or more than 100,000 layers. Thanks to the system, production, scalability, scalability, scalability, scalability, scalability, scalability, scalability, scalability, production.

Technical Specifications

Advanced Automation Features

Your operation gains complete control through integrated feeding systems. Automated hoppers and auger mechanisms distribute mash, crumble, or pellet feeds with ±1% accuracy across all tiers, eliminating manual labor and feed waste.

The Nipple Drinking System provides 360-degree water access at every tier. Food-grade materials prevent bacterial growth, while automated flushing maintains hygiene standards that meet international animal welfare requirements.

Manure management becomes effortless with independent longitudinal PP belts at each tier. Waste transfers to transverse conveyors for centralized collection, drastically reducing ammonia buildup and respiratory issues in your flock.

Egg collection operates continuously without human intervention. Gentle incline conveyors transport eggs from nest areas to central collection points, preserving shell integrity and reducing labor costs by 80%.

Quality Construction and Durability

The structural foundation uses Q235 international bridge steel with 275g/m² hot-dip galvanization treatment. Even in high-ammonia poultry situations, this corrosion-resistant coating prolongs service life beyond 15 years.

Air circulation between stages is improved by our 5 cm raised center structure. By maintaining ideal ventilation rates, this engineering advancement lowers heat stress during the summer and enhances flock health overall.

To make sure the frame can take cumulative stresses from birds, feed, and equipment without deflecting, reinforced weld locations are put through tensile strength testing. All tier configurations maintain structural integrity.

Flexible Customization Options

We offer complete customisation according to the unique needs of your farm. In order to create the best arrangements, site planning services include desired bird capacity, barn size, and the local climate.

Tropical, dry, and temperate conditions can all be accommodated via tier layouts. Modular parts enable you to modify cooling systems, ventilation systems, and housing density in accordance with local biosecurity regulations.

Custom design specifications are accommodated by OEM/ODM manufacturing services. Our technical team creates solutions that easily integrate with the farm's current infrastructure by working directly from your plans.

Installation and Support Services

Comprehensive video guide guidance guidance guidance guidance advisory guidance guidance guidance guidance guidance guidance recommendation guidance guidance. To make setup procedures easier, our technical staff offers detailed instructions in several languages.

For complicated applications, on-site installation support is offered. Skilled specialists come to your site to oversee the building of equipment, adjust automation systems, and instruct your employees on day-to-day tasks.

With dedicated service channels, after-sales assistance is available worldwide. To guarantee more than 20 years of dependable performance, maintenance packages include drinking line cleansing procedures, motor lubrication schedules, and belt tension adjustments.

Proven Global Performance

More than 100 nations throughout Europe, Southeast Asia, and the Middle East successfully use our solutions. This global track record shows dependability in a variety of farming conditions and climates.

Innovation in automation technologies and IoT integration is fueled by ongoing R&D investment. Optional add-ons include mobile app monitoring for temperature, humidity, ammonia levels, and laying rates—accessible from any device.

Energy-efficient designs lower operating expenses while adhering to EU sustainability criteria. Optimized ventilation and low-emission manure management systems reduce your environmental impact without sacrificing output.

Frequently Asked Questions

Q: What is the maximum tier height for your H Frame Automatic Layer Cages?

A: Standard configurations range from 3 to 8 tiers. Custom engineering supports higher arrangements with reinforced structural components tailored to your facility's load-bearing capacity.

Q: How does the system prevent manure accumulation between tiers?

A: Each tier features an independent longitudinal PP manure belt that continuously transports waste to a transverse conveyor. This design eliminates cross-contamination and maintains hygienic conditions.

Q: What maintenance is required for automated components?

A: Routine maintenance includes checking belt tension every 90 days, lubricating motor gears monthly, and flushing drinking lines weekly. Following these protocols ensures decades of trouble-free operation.

Q: Can the feeding system handle different feed types?

A: Yes, automated hoppers accommodate mash, crumble, and pellet feeds. The distribution mechanism maintains ±1% accuracy regardless of feed consistency, ensuring uniform nutrition delivery.

Q: How quickly can you fulfill custom orders?

A: Our standard production cycle ranges from 30 to 60 days depending on order complexity. Rush production schedules are available for urgent projects with advance coordination.

Contact Us for Custom Solutions

Ready to transform your poultry operation with H Frame Automatic Layer Cages? Our team provides free consultation on system design, capacity planning, and integration strategies. Contact Us at admin@huabangsmart.com to discuss your specific requirements and receive a detailed quotation.
